The Efficient M415SE Motherboard for Entry - Level PCs is a cost - effective and reliable solution designed specifically for users who are looking for a basic yet efficient computing platform. This motherboard offers a balance of performance, functionality, and affordability, making it an ideal choice for entry - level desktops used in home, office, or educational settings. With its simple design and easy - to - use features, the M415SE motherboard provides a hassle - free computing experience for users with basic computing needs.
Economical Chipset Design: The M415SE motherboard is built with an economical chipset that provides sufficient processing power for everyday tasks. It supports a range of entry - level processors, ensuring smooth operation for activities such as web browsing, word processing, and light multimedia consumption. The chipset's design also helps to keep the cost of the motherboard down without sacrificing essential performance.
Essential Connectivity Options: It comes with a set of essential connectivity options, including USB 2.0 ports, SATA interfaces, and Ethernet ports. These interfaces allow users to connect common peripherals such as keyboards, mice, external hard drives, and network devices, enabling seamless integration with other components in the PC setup.
Compact and Space - Saving Design: The motherboard features a compact form factor, making it suitable for small - form - factor PCs and mini - towers. Its space - saving design allows for easy installation in limited - space environments, while still providing all the necessary functionality for basic computing tasks.
Energy - Efficient Operation: Designed with energy - efficiency in mind, the M415SE motherboard consumes less power compared to higher - end models. This not only helps users save on electricity bills but also reduces the environmental impact. It is an eco - friendly choice for those who are conscious of energy consumption.
Home Use: In homes, the Efficient M415SE motherboard is perfect for basic computing tasks such as checking emails, browsing the internet, and watching online videos. It can be used to build a simple desktop PC for family members who do not require high - end performance but need a reliable and affordable computing solution.
Office Environments: For office use, especially in small businesses or departments with basic computing requirements, this motherboard can be used to create a fleet of entry - level PCs. It supports common office applications such as word processing, spreadsheet software, and email clients, enabling employees to perform their daily tasks efficiently.
Educational Institutions: In schools and educational institutions, the M415SE motherboard is suitable for computer labs and classrooms. It provides students with a basic computing platform for learning activities such as research, typing assignments, and educational software usage. Its affordability makes it a practical choice for educational budgets.
Value - for - Money Proposition: We understand the importance of providing products that offer excellent value for money. The M415SE motherboard is priced competitively while still delivering reliable performance and essential features. It allows users to build a functional PC without overspending, making it a great option for budget - conscious consumers.
Reliable Performance: Despite its affordable price, the M415SE motherboard is built to last. We use high - quality components and follow strict manufacturing standards to ensure its reliability. It has been tested to withstand the rigors of daily use, providing users with a stable and consistent computing experience.
User - Friendly Design: The motherboard's design is focused on simplicity and ease of use. It comes with clear installation instructions and intuitive interfaces, making it accessible even to users with limited technical knowledge. This allows for a quick and straightforward PC building process.
Responsive Customer Service: Our customer service team is dedicated to providing prompt and helpful support to our customers. Whether you need assistance with product selection, installation, or troubleshooting, we are always ready to help. We strive to ensure that our customers have a positive experience with our products and services.
Motherboard model | CPU | COM | 4K | LAN | USB2.0 | USB3.0 | SSD | Memory | power |
M415SE | Support for Intel Gemini Lake Refresh J and N series CPUs (eg: J4125) | 6 | Support 4K60Hz | 1 | 8 | 2 | 1*MSATA 1*SATA 3.0 | 1*NB-DDR4 8G (MAX) | +12V |
2 | 6 | 2 | |||||||
Single network motherboard defaults to 10USB, dual network motherboard defaults to 8USB | |||||||||
>> Important Note
Power supply interface:
The motherboard DC interface specification 5.5*2.5, optional support for one 4Pin ATX power interface;
The power supply of the motherboard only supports 12V, and the full load is about 30W. It is recommended to use 12V4A or above power supply;
Show interface:
1. The motherboard VGA/VGA pin, HDMI, LVDS/EDP support single display, dual display/triple display copy, dual display/triple display expansion , only single display under DOS;
2. The motherboard supports LVDS by default, and EDP can be changed. EDP uses EDP-B screen cable (20Pin backlight separates independent screen cable); EDP supports resolution 1920*1080@60Hz;
3. The motherboard HDMI interface supports HDMI 2.0 and supports 4K resolution 4096/3840*2160@60Hz;
Mini-PCIE:
1. The motherboard Mini-PCIE supports the coexistence of PCIE signal and USB signal by default, and USB is an independent signal; it supports WiFi/4G/Bluetooth module by default;
2. The motherboard MSATA interface defaults to SATA signal, supports MSATA disk, no USB signal, can be modified to coexist with USB signal, after modification, the built-in F_USB1 pin 1/3/5/7 has no signal; SATA signal can be changed to PCIE signal, after modification, it supports WiFi module;
USB interface:
1. The motherboard supports 10*USB (2*USB3.0, 8*USB2.0) by default;
2. The motherboard USB interface and pins default to S power (no power after shutdown), and can be changed to A power (power after shutdown);
COM port:
1. The motherboard supports 6*COM ports, and supports RS232 by default; among them, COM1 can optionally support RS232/RS422/RS485, which can be set through BIOS;
2. The motherboard JPCOM1/2 pins respectively control COM1/2 pin 9 pin voltage 0V/5V/12V, default 0V;
Network card:
The motherboard supports single Gigabit/100M optional, dual Gigabit/100M optional; Gigabit: single network Realtek 8111H, dual network 8111H+8111H; 100M: single network 8106E, dual network 8106E+8106E; POE cannot be changed powered by;
Sound card:
The motherboard defaults to Realtek ALC662/897 sound card, the green audio interface only supports FRONT_SPK, not MIC_IN, the built-in F_AUDIO pin supports FRONT_SPK and MIC_IN; the USB sound card cannot be changed
>> CPU information
CPU brand | CPU model | Main frequency | Turbo frequency | CPU power consumption | The full load power consumption of the whole board is about |
Intel Celeron | J4025 | Dual core 2.00G | 2.90G | 10W | 30W |
J4125 | Quad-core 2.00G | 2.70G | 10W | 30W | |
N4020 | Dual-core 1.10G | 2.80G | 6W | 30W | |
N4120 | Quad-core 1.10G | 2.60G | 6W | 30W | |
Intel Pentium | J5040 | Quad-core 2.00G | 3.20G | 10W | 30W |
N5030 | Quad-core 1.10G | 3.10G | 6W | 30W |
>> Product Specifications
Motherboard size | 146mm(L)*102mm(W)*23mm(H) | |
CPU processor | Intel® Processor Celeron J4025/J4125/N4020/N4120, Pentium J5040/N5030 | |
Memory support | 1*NB-DDR4 SODIMM memory slot, support single channel 2400MHz memory, low voltage 1.2V, maximum support 8GB | |
Power supply | 1*DC_PWR | Support 12V voltage, the inner diameter of the DC head is 2.5MM The power consumption of the motherboard is about 30W at full load, and it is recommended to use a power supply of 12V/4A or above |
1*DC_JACK ( optional ) | ||
Display function | Intel® UHD Graphics 600 Graphics controller, support single display, double display/triple display copy, double display/triple display expansion, single display under DOS | |
1*VGA DB15 interface | Support resolution 1920*1080@60Hz | |
1*VGA_H1 pin | Support resolution 1920*1080@60Hz (12Pin, 1*12Pin, 2.0mm) | |
1*HDMI 2.0 interface | 4K resolution 4096/3840*2160@60Hz | |
1*LVDS/EDP pin | Support resolution 1920*1080@60 Hz (30Pin, 2*15Pin, 2.0mm) | |
1*LVDS_PWR pin | LVDS voltage control pin (6Pin, 2*3Pin, 2.0mm) | |
1*INVERT pin | LVDS backlight switch control pin (6Pin, 1*6Pin, 2.0mm) | |
Choose one of LVDS and EDP, share a set of pins, default LVDS signal | ||
Internet function | 1/2*RJ45 LAN interface | 100M network card and Gigabit network card are optional, support wake-up on network and PXE diskless boot function (Gigabit: single network 8111H, dual network 8111H+8111H) (100M: single network 8106E, dual network 8106E+8106E) |
1*MINI_PCIE interface | Support WIFI/3G/4G/Bluetooth module | |
Hard disk function | 1*SATA interface | Standard SATA 3.0 hard disk interface |
1*SATA_PWR pin | Hard disk power supply pin, can take power 5V, 12V (4Pin, 1*4Pin, 2.54mm) | |
1*MSATA interface | Supports MSATA 3.0 | |
Sound function | By default, it supports Realtek ALC662/897 HD digital audio codec, 6-channel high-fidelity audio controller | |
1*FRONT_SPK interface | Support audio output | |
1*F_AUDIO pin | Standard audio pin (9Pin, 2*5Pin, 2.0mm) | |
1*JAMP pin | Power amplifier supports 8 ohm 5 watt speaker dual channel output (4Pin, 1*4Pin, 2.0mm) | |
USB function | 2*USB3.0 interface | Rear standard USB3.0 interface, the maximum transmission bandwidth is 5Gbps |
2*USB2.0 interface | Rear standard USB2.0 interface, the maximum transmission bandwidth is 480Mbps (60MB/s) | |
1*F_USB1 pin | Front USB2.0 pins, one set has 2*USB2.0 (9Pin, 2*5Pin, 2.0mm) | |
1*F_USB2 pin | Front USB2.0 pins, one set has 2*USB2.0 (9Pin, 2*5Pin, 2.0mm) | |
1*F_USB3 pin | Front USB2.0 pins, one set has 2*USB2.0 (9Pin, 2*5Pin, 2.0mm) | |
The USB signal of the MSATA interface and the USB2.0 signal of the built-in F_USB1 pin 1/3/5/7 can be selected. | ||
Switch function | 1*F_PANEL pin | Switch, power light, hard disk light, reset pin (9Pin, 2*5Pin, 2.0mm) |
1*AUTO-SW pin | Support hardware control to power on and start (3Pin, 1*3Pin, 2.0mm) | |
Other IOs | 1*COM1 pin | Serial port, COM1 supports RS232/RS422/RS485 optional (9Pin, 2*5Pin, 2.0mm) |
1*COM2 pin | Serial port, support standard RS232 (9Pin, 2*5Pin, 2.0mm) | |
1*COM3-6 pin | Serial port, support standard RS232 (39Pin, 2*20Pin, 2.0mm) | |
1*JPCOM1/2 pin | Can control COM1/2 pin 9 voltage 0V/5V/12V (6Pin, 2*3Pin, 2.0mm) | |
1*SIM card slot | Support SIM card, need SIM card when using 3G/4G | |
1*CLR_CMOS pin | Motherboard reset and discharge pin (3Pin, 1*3Pin, 2.54mm) | |
1*FAN1 pin | Fan pin, does not support temperature control (3Pin, 1*3Pin, 2.54mm) | |
1*GPIO pin | GPIO control pin (10Pin, 2*5Pin, 2.0mm) | |
Operating environment | Working temperature: -10℃~60℃; Working humidity: 5%~95% relative humidity, non-condensing | |
BIOS | AMI BIOS, support timing boot, remote switch machine intelligent identification of equipment | |
Watch dog | Watchdog programming, support hardware reset function (256 levels, 0~255 seconds) | |
Operating system | Support Windows 11, Windows 10, Kirin system, Tongxin system, Linux, etc. | |
