This is a Nano-ITX motherboard. It is very compact. The board uses Intel J series CPUs. These are low-power processors. It supports DDR3 memory. You can add up to 8GB. The board has multiple video outputs. It includes HDMI and VGA ports. You can connect two screens.
This motherboard is good for many uses. It can be a home server. It can be a thin client. You can use it for digital signs. It works well in small spaces. It has a fanless design. This makes it quiet. It has a wide temperature range. It is good for industrial uses. It has multiple network ports. This allows for flexible connections. The board is easy to install. It is a reliable solution.
| Quantity: | |
|---|---|
NANO9F
Elsky/OEM/ODM
Compact Form Factor: The Nano-ITX size of the board is 120mm by 120mm. This small size makes it a perfect fit for tiny PC cases and embedded systems. Its design helps save space.
Low Power Consumption: The motherboard uses Intel Bay Trail CPUs. It has a power draw of about 30W at full load. This design helps reduce energy costs and heat generation.
Flexible Display Support: The board offers multiple video outputs. It has ports for HDMI, VGA, and LVDS. This allows you to connect a single display or set up a dual-display system.
Wide Operating Temperature: This motherboard can operate in temperatures from -10°C to 60°C. This wide range makes it ideal for industrial use and other harsh environments where standard motherboards might fail.
Robust Connectivity: The board includes a variety of ports. It has multiple USB ports (USB 3.0 and USB 2.0) and both SATA and mSATA interfaces for storage. You can also get models with one or two gigabit LAN ports.
Watchdog Function: A built-in watchdog timer can monitor the system. It helps the system recover from software failures automatically. This feature ensures high reliability and stable operation.
Rich I/O Interfaces: The board provides multiple serial ports (COM). This allows for easy connection with a wide range of industrial equipment and external devices. It includes support for RS232, RS422, and RS485.
Industrial Control: The wide temperature range and robust design make it ideal for factory automation. It can control machinery and monitor production lines in harsh environments.
Home Server / NAS: Its low power consumption and small size are perfect for a home server or a Network Attached Storage (NAS) device. It can manage files, stream media, and run simple services 24/7.
Digital Signage: This motherboard can power digital billboards and interactive displays. Its multiple video outputs and reliable operation are crucial for continuous display use in public spaces.
Thin Clients: The compact size and low power use make it a great choice for a thin client or a virtual desktop. It provides a simple terminal to access remote systems.
Mini PCs / HTPCs: It can be used as the core of a small form factor PC or a Home Theater PC (HTPC). It is powerful enough for media playback and basic computing tasks.
1. What is the form factor of this motherboard?
This is a Nano-ITX motherboard. It measures 120mm x 120mm, making it ideal for compact systems.
2. What type of CPU does it use?
It is equipped with an Intel Bay Trail J series CPU. This includes the J1800, J1900, and J2900 models.
3. Does this motherboard support dual displays?
Yes, this motherboard supports dual displays. It features HDMI, VGA, and LVDS outputs.
4. What is the maximum power consumption?
The board's full load power consumption is approximately 30W. It is a low-power design.
5. What operating systems are supported?
This motherboard is compatible with various operating systems, including Windows 10, Windows 8, Windows 7, and Linux.
6. What is the recommended power supply?
It is recommended to use a 12V4A or higher power supply.
