Overview
D25G2 D25G6 is a low-power motherboard. It features an onboard Intel Atom CPU. The design is compact and thin. It operates without a fan. This allows for quiet performance. It supports a desktop ATX power supply.
This board supports dual displays. You can clone or extend your screen. It offers VGA and LVDS outputs.
The board has many interfaces. It includes a Gigabit Ethernet port. There are two SATA ports for storage. You get eight USB 2.0 ports. A PCI slot is also available. You can choose between two or six COM ports.
This motherboard is very versatile. It is built for reliability. It is a good choice for industrial use.
Features
Low Power Consumption: This motherboard uses Intel Atom dual-core processors. It is built for efficiency and low-power use. The design is compact and fanless for quiet operation. This makes it ideal for small spaces and embedded systems.
Versatile Display Options: The board supports dual displays. You can clone or extend your desktop. It provides VGA and LVDS outputs. This allows for flexible display setups. It can run a single display under DOS.
Expandable Connectivity : You get a Gigabit Ethernet port for network access. There are two SATA interfaces for your storage needs. An expansion slot for PCI devices is included. The board also has many USB and COM ports.
Optional configuration : The board supports either two or six COM ports. The MINI-PCIE slot can be used for WIFI modules or MSATA storage. It also supports different SATA and network configurations based on your needs.
Robust and Reliable Design : It is built to operate in harsh conditions. The working temperature range is -20℃ to 60℃. It includes a watchdog function. This feature supports hardware resets. This ensures stable and reliable performance.
Application
Thin Client : This board is ideal for thin clients. It relies on cloud or server computing. Only basic local processing is needed. This works well for remote desktop terminals.
Advertising & Information Displays : Use this motherboard for digital signage. It supports stable 4K video playback. It is designed for long-term, continuous operation.
POS Systems : This board is perfect for point-of-sale systems. It runs custom retail software. The low power use reduces heat. It also helps to keep noise levels down.
Portable Medical Devices : The motherboard is suitable for medical devices. This includes handheld ultrasound machines. It can also power electronic medical record terminals. Its low-power design allows for a long battery life.
Field Monitoring Equipment : This board works well in remote locations. It can power weather stations. It also runs wildlife tracking terminals. The design allows for long-term, unmanned operation.
Service
ELSKY provides strong after-sales support for our D25G2,D25G6 motherboards. We aim for your satisfaction.
Warranty Coverage : All ELSKY motherboards come with a 1-year warranty. This covers defects in materials and workmanship. We stand by our product quality.
Technical Support : Our team offers comprehensive technical support. If you have questions, we can help. We provide guidance for setup and troubleshooting.
Repair and Replacement : Should an issue arise, we offer repair services. If repair is not possible, we can arrange a replacement. This ensures minimal downtime for your operations.
Customer Assistance : We are committed to good customer service. Our staff is ready to assist you. Contact us for any needs regarding your motherboard.
Product Model Ordering Optional
Model | CPU | LAN（RJ45） | COM | USB | Memory（Max） | Power |
D25G2 | D2550 | 1 | 2 | 8 | 4GB | ATX+12V |
D25G6 | D2550 | 1 | 6 | 8 | 4GB |
D25G2-2L | D2550 | 2 | 2 | 6 | 4GB |
D25G6-2L | D2550 | 2 | 6 | 6 | 4GB |
Product Specifications
Size | 170mm*170mm |
CPU | Intel Atom D2550 |
Chipset | Intel D2550+NM10 Plus |
Memory | 1*DDR3 SODIMM memory slot, supports 1333/1600MHz memory, max support 8GB |
Power supply | 1*ATX_CON | Desktop ATX power interface, supporting 12V voltage |
Display | D2550 integrates GMA3600 display core, supports single display, dual display replication, dual display expansion, single display under DOS |
1*VGA DB15 interface | Supports the highest resolution 1920*1200@60HZ |
1*VGA_OUT pin | Supports the highest resolution 1920*1200@60HZ （1*12Pin，2.0mm） |
1*LVDS pin | Supports the highest resolution 1920*1080@60HZ （2*10Pin，2.0mm） |
1*LVDS_PWR pin | LLVDS voltage setting pin （1*3Pin，2.54mm） |
1*INVERT pin | LVDS backlight control pin （1*6Pin，2.0mm） |
Network | 1* RTL8111E gigabit network card chip, supporting network wake-up/PXE function. (Dual Gigabit Ethernet ports optional) |
Storage | 1*SATA1 interface | Standard SATA2.0 hard drive interface, maximum transfer speed of 3.0 Gbps |
1*SATA2 interface | Standard SATA2.0 hard drive interface, maximum transfer speed of 3.0 Gbps |
Sound | Integrated Realtek ALC662 HD digital audio decoder, 6-channel high fidelity audio controller |
1*AUDIO_JACK interface | Supports audio output (interface above), MIC input (interface below) |
1*F_AUDIO pin | Standard audio pin （2*5Pin，2.54mm） |
USB | 4*USB2.0 interface | Rear standard USB 2.0 interface |
1*FUSB1 pin | Front USB 2.0 pins, one set with 2 * USB 2.0 （2*5Pin，2.54mm） |
1*FUSB2 pin | Front USB 2.0 pins, one set with 2 * USB 2.0 （2*5Pin，2.54mm） |
Switch | 1*F_PANEL pin | Switch, power light, hard disk light, restart pin （2*5Pin，2.54mm） |
Other I/O | 1*COM interface | External serial port, supports RS232 |
COM pin | Serial port pin, COM6 optional supports RS422/RS485, 1 * RS422 or 1 * RS485 （2*5Pin，2.54mm） |
1*PS/2 interface | PS/2 keyboard and mouse interface |
1*MINI_PCIE interface | Supports WIFI module and MSATA optional |
1*CLR_CMOS pin | Motherboard reset and discharge pins （1*3Pin，2.54mm） |
1*BAT holder | Battery holder |
1*SYS_FAN pin | Fan pin （1*3Pin，2.54mm） |
1*CPU_FAN pin | Fan pin （1*3Pin，2.54mm） |
1*LPT interface | Standard printing port |
1*PCI slot | Standard PCI slot, capable of connecting independent devices externally |
Operating environment | Working temperature: -20 ℃~60 ℃; Working humidity: 5%~95% relative humidity, no condensation |
BIOS | AMI BIOS, support power on, timed power on, and intelligent recognition of remote power on/off devices |
Watch Dog | Watchdog programming, supports hardware reset function (256 levels, 0-255 seconds) |
Operating system | Supports Windows 7,Windows XP,Linux |
FAQ
1. Q:What processors are on the ELSKY D25G2/D25G6 motherboard?
A:The board features onboard Intel Atom D2550/N2800/N2600 dual-core processors.
2. Q:What kind of memory does this motherboard support?
A:It has one DDR3 SODIMM slot. It supports up to 8GB of memory at speeds of 1333/1600MHz.
3. Q:Can I use two monitors with this motherboard?
A:Yes, it supports dual displays. You can use both mirrored and extended modes via VGA and LVDS outputs.
Q:4. What are the expansion and connectivity options?
A:The board includes a Gigabit Ethernet port, two SATA ports, and one PCI slot. It also has eight USB 2.0 ports and an option for two or six COM ports.
5. Q:What is the power supply requirement?
A:It uses a standard desktop ATX power input.
6. Q:Is this a fanless motherboard?
A:Yes, the ELSKY D25G2/D25G6 has a fanless design. This makes it ideal for quiet operation and small spaces.
7. Q:What are the main applications for this motherboard?
A:It's great for thin clients, digital signage, POS systems, portable medical devices, and field monitoring equipment.
