| Availability: | |
|---|---|
| Quantity: | |
| Model | 15-inch-QM9850 | |
| Motherboard model | QM9850 | |
| Size | 379mm*297mm*61mm | |
| Power supply | 1*DC_IN | The inner diameter of the DC head is 2.5mm and supports 12V / 19V. It is recommended to use the power supply above 12V7A or 19V5A |
| 7th gen CPU | Intel celeron 3865U Dual core 1.8GHz; celeron 3965U Dual core 2.2GHz; Intel core i3-7020U Dual core 2.3GHz; core i3-7100U Dual core 2.4GHz; Intel core i3-7130U Dual core 2.7GHz; Intel core i5-7200U Dual core 2.5GHz, Rui frequency 3.1GHz; core i5-7260U Dual core 2.2GHz, Rui frequency 3.4GHz; Intel core i5-7267U Dual core 3.1GHz, Rui frequency 3.5GHz; core i5-7287U Dual core 3.3GHz, Rui frequency 3.7GHz; Intel core i5-7300U Dual core 2.6GHz, Rui frequency 3.5GHz; core i5-7360U Dual core 2.3GHz, Rui frequency 3.6GHz; Intel core i7-7500U Dual core 2.7GHz, Rui frequency 3.5GHz; core i7-7560U Dual core 2.4GHz, Rui frequency 3.8GHz; Intel core i7-7567U Dual core 3.5GHz, Rui frequency 4.0GHz; core i7-7600U Dual core 2.8GHz, Rui frequency 3.9GHz; Intel core i7-7660U Dual core 2.5GHz, Rui frequency 4.0GHz; | |
| 8th gen CPU | Intel core i3-8130U Dual core 2.2GHz, Rui frequency 3.4GHz; Intel core i5-8250U Dual core 1.6GHz, Rui frequency 3.4GHz; Intel core i5-8350U Dual core 1.7GHz, Rui frequency 3.6GHz; Intel core i7-8550U Dual core 1.8GHz, Rui frequency 4.0GHz; Intel core i7-8650U Dual core 1.9GHz, Rui frequency 4.2GHz; | |
| Chipset | A single chip integrated in the CPU | |
| Memory | 2*NB-DDR4, support 2133/2400MHz, up to support 32G | |
| Network function | Integrated Realtek 8111H Gigabit network card, support network wake-up, network PXE function | |
| Support WIFI / 3G / 4G, support 2 * WIFI antenna rod | ||
| Display function | Integrated intel HD Graphics 610 / 620 graphics controller, support single display, double display replication, double display extension | |
| 1*VGA | Support resolution 1920*1200@60Hz | |
| 1*HDMI | Support 4K resolution 4096/3840*2160@24/30Hz | |
| USB function | 2*USB3.0 | Blue group USB is the USB3.0 speed |
| 6*USB2.0 | Black group USB is USB2.0 speed | |
| Serial port function | 6*COM | Standard DB9 serial port, default support RS232; 1 optional support * RS485 |
| Sound function | Integrated Realtek ALC662 HD digital audio decoder, 6-channel high-fidelity audio controller | |
| 1*SPK | Support audio output | |
| 1*MIC | Support microphone input | |
| The HDMI interface supports the HDMI audio output | ||
| Hard disk function | MSATA / M.2 / 2.5 inch SSD and notebook（32G/64G/120G/128G/240G/256G/512G/1TB...） | |
| Switch function | POWER | switching push-button |
| Operating environment | Operating temperature: -10℃~60℃; Operating humidity: 5%~95% relative humidity, no condensation | |
| BIOS | AMI BIOS, support power-on, timed startup, remote switch on and off intelligent device identification | |
| Watch Dog | Watchdog programming, support hardware reset function (256 level, 0~255 seconds) | |
| Operating system | Windows 10, Windows 8, Linux etc. | |
>> The Characteristics of the Industrial Computer
The industrial computer supports 4K Extreme HD, Fanless, Multi-COM, Multi-network, Multi-USB, Multi-display ports. Full size and dimensions, optional discrete graphics card.
Supports Intel Celeron CPUs: J1900/J4125/J6412/N100, 6th-14th Gen CPUs: Intel CORE i3, i5, i7, i9, etc.
Industrial Computer Series
IPC6900 High-performance Industrial Computer
Size: 210*220*80MM
Supports single and dual LAN ports
2-10 COM ports
HDMI/LVDS/VGA/DP display interfaces
Fully Enclosed Fanless
7*24 hours stable operation
Supports 8th-14th Gen CPUs: Intel CORE i3, i5, i7, i9
IPC6800 Industrial Computer
Size: 205*286*76MM
Support single and dual LAN ports
2-10 COM ports
HDMI/LVDS/VGA/EDP display interfaces
Fully Enclosed Fanless
7*24 hours stable operation
Supports 8th-14th Gen CPUs: Intel CORE i3, i5, i7, i9
IPC6000 Industrial Computer
Size: 205*213*53MM
Support single and dual LAN ports
2-10 COM ports
HDMI/LVDS/VGA/EDP display interfaces
Fully Enclosed Fanless
7*24 hours stable operation
Supports 6th-10th Gen CPUs:Intel CORE i3, i5, i7, i9
Rack-mounted Industrial Computer Series
1U series IPC100U
Size: 430*301*44MM
Supports Intel Celeron CPUs: J1900/J4125/J6412/N100
Supports 6th-14th Gen CPUs: Intel CORE i3, i5, i7, i9
2U series IPC200U
Size: 480*350*88MM
Supports Intel Celeron CPUs: J1900/J4125/J6412/N100
Supports 6th-14th Gen CPUs: Intel CORE i3, i5, i7, i9
4U series IPC400U
Size: 380*351*160MM
Supports Intel Celeron CPUs: J1900/J4125/J6412/N100
Supports 6th-14th Gen CPUs: Intel CORE i3, i5, i7, i9
>> The Applications of the Industrial Computer
ELSKY products help thousands of businesses, widely used in Intelligent city, Intelligent financial, Intelligent retails, Intelligent transportation, Intelligent Medical Care, Intelligent Network Security, Intelligent Commercial Display, Intelligent Education and Conferences, Self-service Cash Registers, Industrial Automation, Industrial control, AI Computing Terminal, AI Robots, 5G IoT, ect.
>> Company Profile
Founded in 2009, ELSKY is a national high-tech enterprise focusing on independent research and development of industrial control motherboards and computers. With more than 16 years of deep development of control terminal industry technology, ELSKY has been at the forefront of industrial control terminal design and development, committed to promoting the automation, intelligence and informationization of high-end manufacturing equipment industry, and providing partners with complete industrial control terminal solutions.
ELSKY has obtained more than 40 intellectual property rights. The products are widely used in industrial control, medical, transportation, network security and other industries, fully supporting the application of visual innovation technology and artificial intelligence technology, and have been strongly recognized by the market and users. ELSKY has won many government recognitions and industry awards, and has passed many major global certifications.
ELSKY is a member of Intel China Intelligent Manufacturing Base, a member of Intel Internet of Things Alliance, and has been awarded Intel Titanium Global Strategic Partner in 2022. The company has launched hundreds of industrial motherboards and OPS based on low-power platforms, industrial PC, with comprehensive functions, exquisite processing, stable operation, which are affirmed by the users and sold well in Europe, America, the Middle East, Southeast Asia and hundreds of other countries and regions. In the field of IoT artificial intelligence innovation, we are willing to work with excellent partners all the way to create a win-win situation!
>> Company Advantage
National High-tech Enterprise, National Specialized New Small Giant Enterprise, Guangdong Industrial Visual Control Terminal Engineering Technology Research Center.
Founded in 2009, with 200+ professional employees, focusing on motherboard and OPS, Industrial Computer solutions for more than sixteen years.
Providing OEM / ODM motherboard and computer service
All kinds of intellectual property rights more than 60 pieces.
Core support: Intel Titanium strategic partner, Intel China Intelligent Manufacturing Base members.
Supply chain support: Intel, ON, Realtek, ITE and other domestic and international OEMs and ODMs.
Wide range of applications: covering Display, Education,Retail, Industrial Automation, Network, Medical, Telecommunications, Metallurgy, Transportation, Electric power, Railroads, aviation, Communications, Finance, etc.
Representative Users and projects: Foxconn, TCL, Lenovo, Daxing Airport, Zhejiang University, etc.
>> FAQs
Q: Who are you?
A: We are Shenzhen ELSKY Technology Co., Ltd.
"ELSKY"is our own brand.
We are "Intel Internet of Things(IOT) solutions alliance"member, "Intel Chinese intelligent manufacture base"member, Intel Titanium Partner and Microsoft CLA Partner.
Q: What do you do?
A: We develop, produce, sell motherboard, Mini PC, Industrial Computer, OPS PC and Industrial Tablet PC.
We have many types of motherboards, like ATX, Mini-itx, Nano-itx, 3.5-inch, 4.0-inch, OPS, Firewall, NUC, x86, embedded, industrial motherboards.
Our products mainly use for industrial production, banking, shops, supermarkets, transportation, medical and other industries.
They also apply to ordering machines, cash registers, ATM, digital signage, advertising machines, spot welders, electronic whiteboards, conference equipment, teaching equipment, multimedia players and other equipment.
Q: How many engineers are there in your company?
A: Now we have 50 engineers and technicians.
For the company to develop better, we moved to our own property rights office in Longgang District, Shenzhen, now we have 6000 square meters office space. Every year we continue to increase our staff to meet the needs of the company's development. Welcome to visit our company.
Q: What's your payment ways?
A: We accept T/T, Western Union, Paypal, Alibaba Trade Assurance, Alipay, Wechat Pay, Cash, etc.
