PC model | CPU | 4K | LAN | USB2.0 | USB3.2 | Type-C | Memory | SSD | Power |
NUC12 | Support Intel Alder Lake 12th generation U/P/H series i3, i5, i7, i9 | 1*HDMI 4K 60Hz / 1* Mini-DP 4K 60Hz / 1*Type_C 4K 60Hz | 1 | 2 | 3 | 1 | 1*NB-DDR4 MAX 32G | 1*M.2 | +12~24V |
NUC13 | Support Intel Raptor Lake 13th generation U/P/H series i3, i5, i7, i9 | 1 | 2 | 3 | 1 |
>> Important Note:
Power supply interface:
The motherboard supports 12~24V wide voltage power supply; DC interface specification 5.5*2.5, can be changed to 4*Pin ATX interface power supply;
The maximum turbo power consumption of the U series CPU is 55W, and it is recommended to use a 9V 8A or higher power supply;
The maximum turbo power consumption of the P series CPU is 64W, and it is recommended to use a 9V 10A or higher power supply;
The maximum turbo power consumption of the H series CPU is 115W, and it is recommended to use a 9V 14A or higher power supply;
Display interface:
1. The motherboard HDMI, Mini_DP, and Type-C support single display, dual display/triple display duplication, and dual display/triple display expansion;
2. The motherboard HDMI 2.0 interface supports 4K resolution 4096/38 40*2160@60Hz;
3. The motherboard Mini_DP supports 4K resolution 4096/3840*2160@60Hz; it does not support DP++;
4. motherboard Mini_DP interface must be converted to HDMI using an active Mini_DP to HDMI cable, otherwise there will be no display; a Mini_DP to DP cable can be used directly;
5. The motherboard Type-C supports 4K resolution 4096/3840*2160@60Hz;
M.2
1. The motherboard M.2-SATA/PCIE supports the Key-M interface. The default M.2 2280 hard disk, and the optional M.2 2242 hard disk; the default support NVME (PCIE) protocol, the hardware can be changed to support the SATA protocol;
2. The motherboard M.2_WIFI supports the Key-E interface M.2 2230 WiFi/Bluetooth module; the M.2 hard drive cannot be modified;
USB interface:
1. The motherboard supports 5*USB (3 *USB3.2 Gen1, 2*USB2.0) and 1*Type-C interface by default; the Type-C interface supports USB function and display function;
2. The external USB interface and built-in USB pins on the motherboard are set to S power by default (no power after shutdown). The external DUAL_USB30_1 USB interface only supports S power and cannot be changed to A power (power after shutdown). Other USB ports can be changed to A power.
COM port:
Motherboard C OM1 optionally supports RS232/RS422/RS485 , through BIOS settings;
The motherboard COM1 supports TTL;
Network Card:
Motherboard supports Intel WG i219V single Gigabit network card, cannot be changed to dual network, cannot be changed to POE power supply;
Sound Card:
1. The motherboard supports Realtek ALC897 sound card by default;
2. The motherboard LINE_OUT audio interface supports LINE_OUT output and MIC_IN input;
>> CPU Information
CPU Specifications | CPU Brand | CPU Model | Cores/ Threads | Frequency | Turbo | CPU basic power consumption (W) | Maximum turbo power consumption (W) |
12th Generation I3 | Core | 1215U | Six cores and eight threads | 1.2G | 4.4G | 15 | 55 |
12th generation I5 | Core | 1235U | Ten cores and twelve threads | 1.3G | 4.4G | 15 | 55 |
1245U | Ten cores and twelve threads | 1.6G | 4.4G | 15 | 55 | ||
12th Generation I7 | Core | 1265U | Ten cores and twelve threads | 1.8G | 4. 8 G | 15 | 55 |
1255U | Ten cores and twelve threads | 1.7G | 4.7 G | 15 | 55 | ||
12th Generation I3 | Core | 1220P | Ten cores and twelve threads | 1.5G | 4.4G | 28 | 64 |
12th generation I5 | Core | 1240P | Twelve cores and sixteen threads | 1.7G | 4.4G | 28 | 64 |
1250P | Twelve cores and sixteen threads | 1.7G | 4.4G | 28 | 64 | ||
12th Generation I7 | Core | 1280P | Fourteen cores and twenty threads | 1.8G | 4. 8 G | 28 | 64 |
1260P | Twelve cores and sixteen threads | 2.1G | 4.7 G | 28 | 64 | ||
1270P | Twelve cores and sixteen threads | 2.2G | 4. 8 G | 28 | 64 | ||
12th generation I5 | Core | 12450H | Eight cores and twelve threads | 2.0G | 4.4G | 45 | 95 |
12500H | Twelve cores and sixteen threads | 2.5G | 4.5G | 45 | 95 | ||
12th Generation I7 | Core | 12800H | Fourteen cores and twenty threads | 2.4G | 4. 8 G | 45 | 115 |
12700H | Fourteen cores and twenty threads | 2.7G | 4.7 G | 45 | 115 | ||
12650H | Ten cores and sixteen threads | 2.3G | 4.7G | 45 | 115 | ||
12600H | Twelve cores and sixteen threads | 2.7G | 4.5G | 45 | 95 | ||
12th Generation I9 | Core | 12900H | Fourteen cores and twenty threads | 2.5G | 5.0G | 45 | 115 |
13th Generation I3 | Core | 1305U | Five cores and six threads | 1.6 G | 4.5G | 15 | 55 |
1315U | Six cores and eight threads | 1.2 G | 4.5G | 15 | 55 | ||
13th Generation I5 | Core | 1334U | Ten cores and twelve threads | 1.3G | 4.6G | 15 | 55 |
1335U | Ten cores and twelve threads | 1.3G | 4.6G | 15 | 55 | ||
1345U | Ten cores and twelve threads | 1.6G | 4.7G | 15 | 55 | ||
13th Generation I7 | Core | 1355U | Ten cores and twelve threads | 1.7G | 5.0G | 15 | 55 |
1365U | Ten cores and twelve threads | 1.8G | 5.2G | 15 | 55 | ||
13th Generation I5 | Core | 1340P | Twelve cores and sixteen threads | 1.8G | 4.6G | 28 | 64 |
1350P | Twelve cores and sixteen threads | 1.9G | 4.7G | 28 | 64 | ||
13th Generation I7 | Core | 1360P | Twelve cores and sixteen threads | 2.2G | 5.0G | 28 | 64 |
1370P | Fourteen cores and twenty threads | 1.9G | 5.2G | 28 | 64 | ||
13th Generation I5 | Core | 13420H | Eight cores and twelve threads | 2.1G | 4.60G | 45 | 95 |
13500H | Twelve cores and sixteen threads | 2.6G | 4.70G | 45 | 95 | ||
13600H | Twelve cores and sixteen threads | 2.8G | 4.80G | 45 | 95 | ||
13th Generation I7 | Core | 13620H | Ten cores and sixteen threads | 2.4G | 4.90G | 45 | 115 |
13700H | Fourteen cores and twenty threads | 2.4G | 5.00G | 45 | 115 | ||
13800H | Fourteen cores and twenty threads | 2.5G | 5.20G | 45 | 115 | ||
13th Generation I9 | Core | 13900H | Fourteen cores and twenty threads | 2.6G | 5.40G | 45 | 115 |
>> Product Specifications
PC size | 110mm(L)*107mm(W)*39mm(H) | |
Motherboard size | 100mm(L)*100mm(W)*32mm(H) | |
CPU Processor | NUC12 | Supports 12th generation Intel Alder Lake U/P/H series i5-1235U, i5-1240P, i7-12600H, etc. |
NUC13 | Support 13th generation Intel Raptor Lake U/P/H series i5-1335U, i7-1360P, i9-13900H, etc. | |
Power supply | 1*DC_IN (Can be changed to 4Pin ATX) | The inner diameter of the DC head is 2.5MM, supporting 12~24V wide voltage power supply The maximum turbo power consumption of the U series CPU is 55W, and it is recommended to use a 9V 8A or higher power supply; The maximum turbo power consumption of the P series CPU is 64W, and it is recommended to use a 9V 10A or higher power supply; The maximum turbo power consumption of the H series CPU is 115W, and it is recommended to use a 9V 14A or higher power supply; |
Memory | 1*SO DIMM slot | Support 2133/2400/2666/ 2933/3200MHz memory, maximum support 32G |
Display functions | Integrated Intel UHD Graphics ultra-core graphics card , supports single display, dual display /triple display copy, dual display /triple display expansion | |
1*Mini-DP interface | Does not support DP++, supports 4K resolution 4096/3840*2160@60Hz | |
1*HDMI 2.0 interface | Support 4K resolution 4096/3840*2160@60Hz | |
1*Type-C interface | Support 4K resolution 4096/3840*2160@60Hz | |
Network Features | 1*RJ45_LAN interface | Intel WGi219V Gigabit LAN, supports network wake-up , PXE function |
1*M.2_WIFI interface | PCIE3.0 signal, support Key-E interface M.2 2230 WIFI/Bluetooth module | |
Hard disk function | 1*M.2 -SATA/PCIE interface | PCIE3.0 signal, supports Key-M interface, default M.2 2280 hard disk, optional M.2 2242 hard disk; The default support is NVME (PCIE) protocol, and the hardware can be changed to support SATA protocol |
Sound Features | Integrated Realtek ALC 897 HD digital audio decoder, 6-channel high-fidelity audio controller; | |
1*LINE_OUT interface | Support LINE_OUT output and MIC_IN input | |
The motherboard HDMI interface supports HDMI display audio output | ||
The motherboard Mini-DP interface supports DP monitor audio output | ||
The motherboard Type-C interface supports Type-C monitor audio output | ||
USB Function | 3*USB3.2 interface | Rear standard USB3.2 Gen1 interface, maximum transmission bandwidth is 5Gbps |
1*Type-C interface | Standard Type-C3.0 interface, can connect USB devices | |
2*USB2.0 interface | Front standard USB2.0 interface | |
Switch function | 1*POWER button | Switch button |
1*AUTO_SW pin | Hardware power-on control pin (3Pin, 1*3Pin, 2.0mm) | |
Other I/O | 1*COM1 port | Support standard RS232 /RS422/ RS485 optional ( BIOS setting ) |
1*CLR_CMOS pin | Motherboard discharge, reset pin (3Pin, 1*3Pin, 2.0mm) | |
1*CPU_FAN pin | CPU fan pin, supports temperature control (4Pin, 1*4Pin, 1.25mm) | |
Operating Environment | Working temperature: -10℃~60℃; Working humidity: 5%~95% relative humidity, no condensation | |
BIOS | AMI BIOS, supports power-on, scheduled power-on, remote power on and off, and intelligent device identification | |
Watch Dog | Watchdog programming, support hardware reset function (256 levels, 0~255 seconds) | |
Operating system | Support Windows 10, Windows 11, LINUX, etc. | |
