Industrial PC with Intel Celeron J1900 Celeron J1800 Pentium J2900 HDMI VGA for Windows 10 Windows 8 Windows 7 Linux

CPU Processor

Intel® Processor Celeron J1900 , Celeron J1800, Pentium J2900

Chipset

Intel Bay trail SOC chipset

Power supply

1*DC_JACK

The inner diameter of the DC head is 2.5MM and supports 12V

The full load power consumption of the motherboard is about 25 W. It is recommended to use a 12V 4 A or higher power supply.

Memory

1*NB-DDR3L memory, low voltage 1.35V memory, support 1333/1600MHz memory, maximum support 8G

Display functions

Intel(R) HD Graphics graphics controller , supports single display, dual display copy, dual display expansion, single display under DOS

1*VGA DB15 interface

Support resolution 1920*1080@60HZ

1*HDMI 1.4 interface

Support resolution 1920*1080@60HZ

Network Features

1*RJ45 LAN

RTL8111 H Gigabit network card chip , supports network wake-up and PXE diskless boot functions .

1*Mini-PCIE interface

Support WIFI/3G/4G/Bluetooth etc.

Hard disk function

1*SATA1 interface

Standard SATA2.0 hard disk interface, maximum transmission speed 3.0 Gbps

1*SATA-PWR pin

Hard disk power supply pin, can take power 5V, 12V (4Pin, 1*4Pin, 2.54mm)

1*MSATA interface

Support standard MSATA 2.0

Sound Features

Integrated Realtek ALC662 /660/892 HD digital audio decoder , 6-channel high-fidelity audio controller

1*LINE_OUT interface

Support audio output

1*JAMP pin

The amplifier supports 8 ohm 5 watt speaker dual channel output (4 Pin, 1*4Pin, 2.0mm)

USB Function

1*USB3.0 interface

Standard USB3.0 interface

7*USB2.0 interface

Standard USB2.0 interface

Switch function

1*Power

Switch button

Other I/O

1*COM1 port

Serial port, support RS232/RS422/RS485 optional

1*COM2 port

Serial port, supports standard RS232

1*JPCOM1 pin

Control the voltage of COM1 pin 9: 0V/5V/12V optional ( 6Pin, 2*3Pin, 2.0mm)

1*JPCOM2 pin

Control COM2 pin 9 voltage 0V/5V/12V optional ( 6Pin, 2*3Pin, 2.0mm)

1*SIM card slot

Support SIM card, SIM card is required when using 3G/4G

1*J_GPIO pin

GPIO control pin ( 10Pin, 2*5Pin, 2.0mm)

Operating Environment

Working temperature: -20℃~60℃; Working humidity: 5%~95% relative humidity, no condensation

BIOS

AMI BIOS, supports power-on, scheduled power-on, remote power on and off, and intelligent device identification

Operating system

Supports Windows 10, Windows 8, Windows 7, Linux, etc.
